Nitrocellulose Integrated Powder Actuated M6 Ceiling Nails for Construction

Description:

The integrated powder actuated ceiling nails are also named integrated fasteners, power drive pins, power pins. It combines the function of powder loads and drive pin, integrating power and nail into one body, which very creatively improved the convenient use of the fastening tools and traditional fastening system. The integrated ceiling fasteners are mainly used for the bridge brackets, the water and electricity assembling on the ceiling, the air conditioning wind pipes etc. It allows people standing on the floor and do the ceiling work with an extendable fastening tool. Drilling the hole in the ceiling, just takes 1 second, very fast and high efficiency. Besides, the integrated fasteners are durable with long service life, and their loading bear capacity is at least 300kgs, very strong and safe. Upgrade your construction operation way now with this smart innovation

Send email to us

Product Detail

Product Tags

Feature

1. High hardness.
2.Strong penetration.
3.2mm thickness material.
4.Hot galvanizing surface.
5.Good stability and safety

The integrated ceiling nail is a new type of ceiling decoration material, which is favored by users at home and abroad due to its unique design and advantages. The integrated powder actuated ceiling nail is usually made of steel for strong support and durability. Its special structural design enables the suspended ceiling to bear a large weight and maintain overall stability. At the same time, the integrated ceiling nails can also be customized according to personal preferences and needs. In general, the integrated ceiling nail has unique design, superior performance and attractive decorative effect, so it has attracted much attention and is widely used in various interior decoration projects.

Product Parameters

1. Use a steel sheet with a thickness of 2mm, and the thickness of the coating is not less than 5μ.
2. When shooting C30-C40 concrete, the actual measurement of the pull-out force of the powder actuated nail reaches 4200-5800N2. The strength of the concrete is different, and the depth of the integrated nail rod injected may produce different data. A certain safety factor is taken. Generally, the pull-out load of a single decorative ceiling nail force applies to loads less than 100KG.
3. U-shaped angle piece model: M6.

Application

The actuated ceiling nail is widely suitable for fixing ceiling, light steel keel, pipe, bridge, water, electricity, air conditioner installation.

Special Design

Double base propellant, more safe than single or so-called multi propellant. The power part of the integrated ceiling nail is made with nitrocotton and nitroglycerin or other explosive plasticizers as its basic energy component. Generally used for large caliber artillery and mortar firing charges.
