The powder-actuated tool offers significant advantages over conventional methods such as casting, hole filling, bolting, or welding. One notable benefit is its self-contained power source, eliminating the need for complex cables and air hoses. Operating the nail gun is simple. Initially, the user loads the required nail cartridges into the tool. Then, they insert the corresponding drive pins into the device. Lastly, the operator directs the nail gun towards the desired location, pulls the trigger, and activates a forceful impact that effectively embeds the nail or screw into the material.
Model number | JD450 |
Tool length | 340mm |
Tool weight | 3.2kg |
Material | Metal+plastic |
Compatible fasteners | S1JL Power loads and driving pins |
Customized | OEM/ODM support |
Certificate | ISO9001 |
Application | Built construction, home decoration |
1.The utilization of powder-actuated tools can improve worker efficiency and decrease physical exertion, resulting in time efficiency.
2.By employing powder-actuated tools, objects can be secured with greater stability and durability, ensuring robust fastening.
3.Powder-actuated tools aid in minimizing material damage and reducing the potential risks and hazards associated with the securing process.
1.Prior to usage, carefully review the provided instructions.
2.Under no circumstances should the nail holes be directed towards oneself or others.
3.It is mandatory for users to wear appropriate protective gear.
4.This product is restricted to authorized personnel only and should not be operated by minors.
5.Avoid using fasteners in areas that are susceptible to flammability or explosive hazards.
1.Position the JD450 muzzle perpendicular to the work surface, ensuring the tool remains level, and compress it fully without any tilting.
2.Maintain firm pressure against the work surface until the powder load is released. Activate the trigger to discharge the tool.Once the fastening is completed, withdraw the tool from the work surface.
3.Discharge the powder load by firmly grasping and swiftly pulling the barrel forward. This action will expel the powder load from the chamber and reset the piston, preparing it for reloading.
